The Slash Assembly Kit adds a fun and exciting dynamic to your RC experience. Build your Slash from the ground up with all the required parts and electronics included in the box. Battery and charger sold separately. You'll get the convenience of a TQ™ 2.4GHz radio system, powerful Titan® electric motor, and waterproof XL-5 electronic speed control. All the parts are organized neatly in labeled bags with a fully illustrated color manual to make building rewarding and fun. The Slash assembly kit is perfect for drivers of almost any age or skill level. Build one yourself and experience RC fun the Traxxas way—fast, fun, and easy to use!
Features
Clear ProGraphix® pre-cut body
Includes window masking, decals, and custom masking decals
Scale dimensions and looks of actual short course off-road race trucks
The Slash reaches speeds in excess of 30 mph using a 23-tooth pinion gear and accessory 7-cell Power Cell battery (both sold separately)*
Powerful Titan® 12T 550 modified motor with internal cooling fan
TQ 2.4GHz Radio System
Race in dirt, mud, water, and snow thanks to Traxxas' innovative water-sealed electronics
XL-5 Waterproof Electronic Speed Control
Innovative watersealed design
Forward/reverse/brake
EZ-Set® push-button setup
Thermal shutdown protection
LiPo and NiMH compatible with two-stage low-voltage detection
Three easy-to-program drive profiles
Equipped with Traxxas High-Current Connectors (patented)
Backed by the Traxxas Lifetime Electronics Warranty
Digital high-torque waterproof steering servo
O-ring sealed watertight receiver box keeps the micro receiver dry
Long-wheelbase fiber-composite monocoque chassis
13.2 inch wheelbase
Over 3.5-inches of ground clearance
Easy access battery compartment
Adjustable battery hold down accepts 6- and 7-cell flat packs and 7-cell hump packs (sold separately)
Chassis nerf bars absorb impact and support the body
Scale front and rear tube-style bumpers
Sturdy body mounts incorporate reinforced washers for additional body support
Efficient Magnum 272™ metal-gear transmission with ball bearings
Sealed gearbox protects the transmission with beefed up motor guard for extra protection
Torque-Control™ slipper clutch system
External gear cover with easy slipper access
Reliable composite planetary gear differential with a steel ring gear
Heavy-duty telescoping U-joint driveshafts and yokes
Adjustable steel turnbuckles and captured rod ends
Precision hex hardware throughout
Efficient rubber-sealed ball bearings
Fully adjustable Ultra Shocks™ with X-ring technology
Progressive rate white powder coated shock springs with race-tuned responsive spring rate
Licensed BFGoodrich Mud Terrain T/A tires for superior on- and off-road traction
Includes performance foam inserts and satin chrome 5-spoke wheels
Specifications
Length: 22.36 inches (568 mm)
Front Track: 11.65 inches (296 mm)
Rear Track: 11.65 inches (296 mm)
Weight: 76.2 ounces (2.16 kg)
Height (overall): 8.43 inches (214 mm)
Wheelbase: 13.2 inches (335 mm)
Front Shock Length: Long
Rear Shock Length: XX-Long
Front Tires: BFGoodrich Mud-Terrain T/A
Rear Tires: BFGoodrich Mud-Terrain T/A
Front Wheels: 2.2″ Satin-Finish
Rear Wheels: 2.2″ Satin-Finish
Speed Control Type: Waterproof XL-5 ESC with
low-voltage detection
Motor (electric)Titan: 12T 550 (12-turn)
Gear Ratio (internal): 2.72 (final drive: 12.58)
Differential Type: Steel Composite Planetary
Gear Pitch: 48-Pitch
Transmission: Metal Gear Magnum 272™
Steering: Bellcrank
Chassis Type: Modified Tub
Chassis Material: Composite Nylon
Center Ground Clearance: 3.5 inches (89 mm)
Top Speed: 30+mph**
Skill Level: 1
Radio System: TQ 2.4GHz Radio System (2-channel)
Battery Tray Dimensions: 165 mm x 49.5 mm x 23 mm, 25 mm
Cell Battery (7-cell NiMH or 2-cell LiPo)
Whats in the box
Unassembled Slash 2WD chassis
TQ™ 2.4GHz radio system
Waterproof XL-5™ electronic speed control
Titan® 12-Turn 550 motor
Waterproof high-torque steering servo
BFGoodrich Mud-Terrain T/A tires with foam inserts, mounted on satin chrome 5-spoke wheels
Pre-cut clear Slash body with decals and window masking
Includes custom masking decals for unique paint designs
Full-color step-by-step assembly manual
Required to complete
Battery with Traxxas High-Current Connector
6 or 7 cell NiMH battery pack
2s LiPo battery pack
Battery charger
Metric hex drivers
1.5 mm, 2.0 mm, 2.5 mm
Basic hand tools
Screwdrivers, needle nose pliers
Safety glasses
Polycarbonate paint
| Product Code | TRX58014-4 |
|---|---|
| Bundle Avaliable | No |
| LiPo | No |
| Pre Order | No |
| Discontinued | No |
| EAN / Barcode | 020334587619 |
| Brand | TRAXXAS |
| Weight | 0.200000 |
| Product Type | Electric Car |
| skill levels | Intermediate |
| Model Type | Trophy Truck |
| Fuel Type | Brushed Motor |
| Scale | 1:10 Scale |
