FTX B4X 4WD 1/10 RC Race Buggy Roller Chassis - FTX5468

The FTX B4X Roller Chassis is the rolling platform from the B4X 1/10 4WD race buggy, supplied without motor, radio, servo or ESC so you can build the electronics package of your choice around a race-proven chassis. It suits racers and experienced builders who already have preferred electronics on hand, rather than newcomers wanting an out-of-the-box vehicle, and it gives you a lighter, more customisable starting point than buying a complete RTR buggy and stripping out its electronics.

About the FTX B4X Roller Chassis

This is the same 1/10 4WD race buggy platform used in the B4X RTR, sold as a roller: chassis, drivetrain and suspension are complete and pre-built, but there's no motor, ESC, servo or radio fitted, and the polycarbonate body is supplied clear and unpainted.

The chassis itself is 2.5mm 7075-T6 aluminium with carbon fibre front and rear shock towers, running a shaft-driven 4WD transmission with front, centre and rear metal geared differentials and full rubber-sealed ball bearings throughout. CNC large-bore, hard-anodised shocks and variable pill inserts allow the suspension geometry to be tuned, so the chassis can be set up for a specific track in the same way as the complete RTR buggy.

Because it's a roller, you'll need to source and fit your own motor, ESC, servo, radio system and wheels/tyres before it will run, plus paint for the body if you want it finished rather than clear. That makes it a better fit for someone building to a specific spec or reusing electronics from another buggy than for a first RC purchase; expect a proper building and setup session before it's ready to drive.

Key Features

• Shaft-driven 4WD with front, centre and rear metal geared differentials — even power delivery front to rear
• 2.5mm 7075-T6 aluminium chassis and carbon fibre shock towers — stiff, durable race-buggy base
• CNC large-bore, hard-anodised shocks — controlled damping for racing and bashing
• Adjustable suspension geometry with variable pill inserts — toe-in, anti-squat, roll centre, kick-up and track width can all be tuned
• Full rubber-sealed ball bearings throughout — smoother running and easier maintenance
• Clear, unpainted polycarbonate body and rear wing — ready for your own paint scheme

Specifications

• Scale: 1/10
• Length: 385mm
• Width: 250mm
• Height: 146mm
• Wheelbase: 278mm
• Ground Clearance: 25mm
• Gear Ratio: 8.7:1
• Weight: 1600g (without battery)
• Drive System: Shaft-driven 4WD
• Body: Clear polycarbonate, unpainted

What's In The Box

• Built FTX B4X roller chassis (7075-T6 aluminium, carbon fibre shock towers)
• Shaft-driven 4WD transmission with metal geared differentials, fitted
• CNC-machined suspension hardware and aluminium shocks, fitted
• Clear 1mm polycarbonate body and rear wing
• FTX decals

What You Need To Complete

• Radio system
• Speed controller (ESC)
• Motor
• Servo
• 2S/3S shorty LiPo battery
• LiPo balance charger
• Wheels and tyres
• Paint for the body
