Rc4Wd Trailfinder 2 Lwb Rtr W/ 1987 Toyota Xtracab Hard Body
- Product Code
- Z-RTR0064
Description
RC4WD TRAILFINDER 2 LWB RTR WITH 1987 TOYOTA XTRACAB HARD BODY
Bringing the iconic Toyota look of the 80s comes the new RC4WD Trail Finder 2 "LWB" RTR w/ 1987 Toyota Xtracab Hard Body Set (White)! This new RTR truck features a glossy white hard body with an engine bay, painted interior, exclusive decal sheet, and light kit that is sure to captivate scale aficionados! Included hop-ups are ultimate scale shocks, inner fenders, and premium wheels and tires that elevate the scale detail and authenticity!
This Trail Finder 2 "LWB" chassis is equipped with an R3 Single Speed Transmission, 540 Crawler Brushed Motor, and Outcry III Waterproof ESC, ensuring you get the same great performance and durability.
Don't miss this retro exclusive scale experience!
FEATURES
- 1987 Toyota Xtracab Body Set in White
- Realistic Billet Aluminum Ladder Frame Chassis
- R3 Single Speed Transmission
- Center Mounted Realistic Hammer Transfer Case
- 540 Crawler Brushed Motor 45t
- Outcry III Waterproof ESC
- 6-Cell 3000Mah Nimh Battery Pack
- Yota II Ultimate Scale Cast Axles (XVD)
- Twister High Torque Metal Gear Digital Servo
- RC4WD Ultimate Scale Shocks (70/90mm) (Yellow)
- Stamped Steel 1.7" Beadlock SR5 Wheels (Chrome)
- RC4WD BFGoodrich All Terrain K02 1.7" Scale Tires
- Yota 22RE Engine Bay
- RC4WD Marlin Crawler Side Plastic Sliders
- RC4WD Inner Fender Set for Toyota 4Runner and Xtracab
- NiMH Peak Battery Charger
- Xr3 3-Channel 2.4Ghz Transmitter/Receiver Radio
SPECIFICATIONS
Hammer Transfer Case
Ratio: 1.47: 1
Gears: Wide .8 Mod Steel Gears
Features: 8 Bearings, Cast Casing, Hardened Gears
R3 Single Speed Transmission
Ratios: Pinion/Spur 14/64 = 4.57:1
Internal Ratio: = 1.78:1
Gears: Wide Steel .8 Mod, Delrin Spur, Slipper Clutch
Yota II Ultimate Scale Cast Axles
Ratio: 15/40 = 2.67:1
Width at Hex (Using 4mm TF2 Hexes): 178.2mm
Trail Finder 2 "LWB" Chassis
Billet Aluminum Constriction
Adjustable Shock Hoops
Drive Shafts
High Quality Plastic Material
Durable High Steel Yokes
Wheels
Type: Stamped Steel 1.7" Beadlock SR5 Wheels (Chrome)
Hub: 12mm Hex
Width: 23.0mm (0.90")
OD: 47.0mm (1.85")
TF2 Truck Dimensions
Wheelbase: 314.2mm (12.4")
Width: 206.0mm (8.1")
Height: 225.5mm (8.9")
Ground Clearance: 58.0mm (2.3")
Final Drive Ratio: 31.93:1
WHAT'S INCLUDED
- 1 x RC4WD Trail Finder 2 "LWB" RTR w/ 1987 Toyota XtraCab Hard Body Set (White)
NOTES
- While some components may come assembled, we always recommend that you check the products to ensure all hardware is tight. In some cases, you may want to apply thread lock to some of the hardware that is already installed.
- Use good quality hex drivers to avoid stripping screw heads.
- Use thread lock when putting metal screws into metal parts.
- Steps marked with an asterisk (*) require thread lock.
- Use thread lock sparingly.
- Do not over tighten screws otherwise you may strip the thread.
More Information
Product Code | Z-RTR0064 |
---|---|
Bundle Avaliable | No |
LiPo | No |
Pre Order | No |
Discontinued | No |
EAN / Barcode | 639302616901 |
Brand | rc4wd |
Weight | 3.500000 |
Product Type | Electric Car |
